Heavy Duty Excavator

Heavy Excavator 20ton Trenchers Wheel Digger For Sale

With a powerful 20-ton capacity, the excavator offers excellent digging performance and mobility in different terrains. Its advanced features, including a spacious operating compartment, responsive controls and a range of accessories, ensure efficient operation and higher productivity. Whether digging, ditching or material handling, the JG230 wheel excavator delivers outstanding results, making it an indispensable asset for any construction project.


  • Item NO.:

    JG-230S
  • Lead Time:

    15-45days
  • Product Origin:

    China
  • Brand:

    JingGong
  • Shipping Port:

    xiamen
  • Payment:

    L/C or T/T
  • Price Range:

    5-10/88000$
  • Price Range:

    1-5/96000$
  • Color:

    blue/orange/yellow

how can we help you

how can we help you Contact Us
  • Product Detail
  • Technical Specifications

Heavy Excavator 20ton Trenchers Wheel Digger For Sale

Thanks to its wheeled design, the 20-ton excavator offers excellent mobility, making it suitable for both urban and rural environments. High reach excavator for sale can easily navigate through confined spaces, narrow roads, and uneven terrains, providing flexibility and accessibility to different job sites.




Features Of 20 Ton Excavator



Efficient Material Handling: With its strong lifting capacity and optional attachments such as grapples and buckets, the 20-ton wheel excavator is highly effective in material handling tasks. It can efficiently load, transport, and unload various materials, including soil, rocks, debris, and construction materials, making it a valuable asset in construction, waste management, and forestry industries.




Main Parameters


Length*width*height

9600*2990*3000mm

Rated Power

128.5KW

Machine weight

22300KG


Main Parts of Hydraulic Excavator


Optional excavator working devices of JingGong excavator manufacturer china



Efficient Material Handling: With its strong lifting capacity and optional attachments such as grapples and buckets, the 20-ton wheel excavator is highly effective in material handling tasks. It can efficiently load, transport, and unload various materials, including soil, rocks, debris, and construction materials, making it a valuable asset in construction, waste management, and forestry industries.



Why Choose Us


At Quanzhou Jingli Engineering And Machinery Co., Ltd., we are constantly seeking to improve and enhance our product offerings. We stay up-to-date with the latest trends and technology in the industry, enabling us to develop excavators that are both innovative and efficient. We are always seeking new and better ways to serve our customers and exceed their expectations.



Company


company photo of JingGong China excavator manufacturer

We are a leading manufacturer and exporter of wheel excavators, crawler excavators, sugarcane harvesters, sugarcane grab loaders, multi-function excavators. We have nearly 20 years of professional experience, and our products have been exported to many countries.


If you are interested in any of our products or would like to discuss a custom order, please feel free to contact us. We are looking forward to forming successful business relationships with new clients around the world in the near future. We sincerely hope to cooperate, develop together and build a good future with you. China Jing Gong is your best choice for kinds of excavators in China.



Workshop Display

Workshop display of Jing Gong china excavator supplier


Our company abides by the business philosophy of "quality first, customer first" to ensure product quality. We have rigorous production procedures, and each production process is carried out under strict quality inspection.Only after passing the inspection can they move on to the next procedure. At the same time, we insist on creating a neat, clean and safe working environment.


Process

Process of excavator of Chinese excavator supplier (JingGong)

Exhibition Show

Exhibition show of Jing Gong excavator munufacturer

Certificates

Certificates of Jing Gong mechinery munufacturer




SPECIFICATIONS
RANGE OF OPERATION Boom length 5700mm
Arm length 2900mm
Maximum digging radius 9873mm
Minimum turning radius 3560mm
Maximum digging depth 6592mm
Maximum vertical mining depth 3929mm
Maximum digging height 9616mm
Maximum unloding height 6830mm
The radius of the end of gyration platform 2794mm
DIMENSION (Length*width*height) travel position 9600*2990*3000mm
Wheel base 3635mm
Track Gauge 2400mm
Width Of Crawler 600mm
Total width of the car 2990mm
Total length of walking mechanism 4440mm
The total width of belt off 2980mm
Ground clearance of counterweight 1096mm
Min ground clearance 475mm
TECHNICAL PARAMETERS Angle of rotation 360°
Machine weight 22300kg
Engine model Isuzu
Rated Power 128.5KW
Rotary speed 10.7min
Walking speed(high/low) 5.9-3.2km/h
Ground specific pressure 43.5kpa
Climbing ability(%) 70%
Digging force 77.4KN(standard)/81.3KN(turbocharged)
Volume Of Bucket 1.2m3
